About the product
Idea revolving doors are for interiors only and are made of an aluminium frame with a glass panel. Related models are Ideanet doors (with a metal mesh) and Idealine doors (with attractive divided glass). Idea doors can be only single leaf. The Idea line offers an optional side window panel. Idea revolving doors are intended for Garde doorframes.
The Garde doorframe goes into the existing construction opening. Idea revolving doors are non-rebated and have a door leaf 40 mm thick. Maximum dimensions of Idea revolving doors are 1,036 mm x 2,700 mm + slot. Weight of 1 m² Idea door with glass 5 mm thick is 15 kg.
Gallery / inspiration
Technical information
Standard width of passage | according to standard Idea door leaf dimensions by JAP |
Standard height of passage | according to standard Idea door leaf dimensions by JAP |
Custom passage height | 1,975 - 2,700 mm |
Minimal thickness of finished crossbar | 60 mm |
Materials
- the door frame is made of anodized aluminium profile with surface options according to the RAL, K7, NCS swatch books.
- glass panel 5 mm thick
- types of glass door panels: clear glass, extra clear glass, Planibel (tinted glass), satinized (milk glass), satinized antiscratch, sandblasted glass
Fittings
- Grande door handle
- Fine door handle
- Elity door handle
- Garde hinge
