Tracks on ceiling
Trix Trendy
The Trix Trendy system wins customers mainly with its simple design and function, and its excellent technical sophistication
About the product
- a modular system of several aluminium profiles that snap together to form a number of track versions
- the track can be installed on mounting panel above a clean construction opening or above a mounting panel
- the distance of the sliding doors from the wall depends on the choice of profiles of various thicknesses and their combination — called “small and large backs” — which bear the actual track profile
- as a single track, it is suitable for installation above the preserved original mounting panel from revolving doors
- optional synchronous track
- the height of the front aluminium slat is 85 mm
- for single-leaf or double-leaf doors weighing no more than 100 kg per leaf
- custom production based on customers’ individual needs
- combining large and small backs extends the width of the whole system
Gallery / inspiration
Technical information
| Maximum weight of each door leaf | 120 kg |
| Maximum width of each door leaf | 1500 mm |
| Maximum leaf height | 2 600 mm |
| Mounting | on wall, above mounting panel, to ceiling |
Manuals, certificates
Materials
- drawn aluminium
- option for textured and smooth surface treatments from the RAL K7 (except for metallic and reflective shades), NCS or Creative Metallic swatch books
